Specifications for Beam and Tack-Welded Box |
|
min |
max |
|---|---|---|---|
| Web height | mm | 200 | 2500 |
| Web thickness | mm | 8 | 30 |
| Flange width | mm | 150 | 1250 |
| Flange thickness | mm | 8 | 50 |
| Weight | Kg/m | up to 2000 | |
| Length | mm | 2000 | up to 25000 |
|
Specifications for Beam Assembled On-line |
|
min |
max |
|---|---|---|---|
| Web height | mm | 1000 | 1530 |
| Web thickness | mm | 8 | 30 |
| Flange width | mm | 800 | 1250 |
| Flange thickness | mm | 8 | 50 |
| Weight | Kg/m | up to 2000 | |
| Length | mm | 2000 | up to 25000 |
